Camera-assisted positioning
The Flat-bed cutting plotter InkOne CP4 is a fixed-surface digital cutting machine equipped with a camera positioning system using printed registration marks. After manually positioning the camera on a reference point, the machine automatically performs contour cutting with high precision and accurate alignment.
Intuitive control
Equipped with a capacitive LCD touchscreen, the InkOne CP4 allows users to quickly and easily manage cutting parameters, speed, pressure, copies and files. Its intuitive interface simplifies daily operation and streamlines production, even in high-demand environments.
Stable precision
Thanks to its high-precision servo motor, it delivers smooth, accurate and quiet movements while maintaining stability even at high cutting speeds.
Flat-bed cutting plotter InkOne CP4 for DTF and UV DTF
The Flat-bed cutting plotter InkOne CP4 is a digital flatbed cutting machine designed to perform precise contour cuts on printed transfers. It uses a camera positioning system with registration marks that ensures accurate alignment between the printed design and the cutting path.
- Camera positioning system with registration marks for precise contour cutting.
- Allows working with DTF films, UV DTF films, vinyl, paper, cardboard, etc. of up to 1.2 mm thickness.
- Uses vacuum adsorption to keep the material stable during the cutting process.
- Reaches cutting speeds of up to 1000 mm/s for efficient production.
- Offers multiple connectivity options: USB, USB drive, Ethernet and WiFi.
- Includes an emergency stop button for safe operation in professional environments.
INTRODUCTION
InkOne CP4
Benefits of the Flat-bed cutting plotter InkOne CP4
Frequently Asked Questions
The Flat-bed cutting plotter InkOne CP4 is a digital flatbed cutting machine designed to perform precise contour cuts on DTF films, UV DTF films, vinyl and similar materials. It is used to convert printed sheets into perfectly cut transfers, improving the final finish and optimising the workflow in customisation workshops.
The InkOne CP4 uses a camera positioning system based on printed registration marks on the sheet. The cutting file is loaded into the machine beforehand and the operator manually positions the camera over one of the reference points.From this initial calibration, the machine automatically performs the contour cutting of all the images on the sheet with high precision and alignment.
The InkOne CP4 allows cutting DTF films, UV DTF films, adhesive vinyl, paper, cardboard and similar materials, with a maximum thickness of up to 1.2 mm. Cutting pressure and speed can be adjusted according to the material to ensure optimal results.
Compared with manual cutting, the InkOne CP4 offers greater precision, repeatability and consistency for every piece. It enables faster and more reliable work, reducing alignment errors and improving the final quality in batch production.
The InkOne CP4 has an effective cutting area of up to 300 × 420 mm, suitable for working with standard sheets used in DTF and UV DTF without the need to divide the design.
The Flat-bed cutting plotter InkOne CP4 incorporates a high-precision servo motor drive system that ensures smooth, stable and quiet movements while maintaining accuracy even in continuous production.
The InkOne CP4 features an LCD touchscreen that allows intuitive management of parameters and files. It also offers connectivity via USB, USB drive, Ethernet network and WiFi, making integration easy in different production environments.
Yes. It is designed for workshops that regularly work with DTF and UV DTF and require a reliable, precise and consistent cutting system. Its mechanical stability and cutting speed allow an efficient workflow in repetitive production.
The Flat-bed cutting plotter InkOne CP4 includes a 12-month warranty, excluding wear parts such as blades. Coverage is subject to the use of original InkOne consumables.
